Part Number : 2N3440

Function : 1A, 300V, NPN Low Power Silicon Transistor

Package : TO-39, TO-205AD Type

Maker : Microsemi Corporation

Pinouts :
2N3440 datasheet

Description :

This family of high-frequency, epitaxial planar transistors feature low saturation voltage.

Absolute maximum ratings ( Ta=25°C )

1. Collector to Base Voltage : Vcbo = 250 V

2. Collector to Emitter Voltage : Vceo = 300 V

3. Emitter to Base Voltage : Vebo = 7 V

4. Collector Current : Ic = 1 A

5. Total Dissipation : Pc = 0.8 W

6. Junction Temperature : Tj = 200°C



7. Storage Temperatue : Tsg = -65 ~ +200°C








Datasheet PDF Download :
2N3440 pdf

Others datasheet of same file : 2N3439, N3440
