Part Number : K2959

Function : 30V, 50A, Silicon N-Channel MOSFET, Transistor

Package : TO-220AB

Maker : Hitachi , Renesas Electronics

Pinouts :
K2959 datasheet

Description :



Features

•  Low on-resistance  RDS(on)= 7mΩ typ.

•  4V gate drive devices.

•  High speed switching



Absolute Maximum Ratings (Ta = 25°C)

1. Drain to source voltage : VDSS = 30 V

2. Gate to source voltage : VGSS = ± 20 V

3. Drain current : ID = 50 A

4. Channel dissipation : Pch = 75 W

5. Channel temperature : Tch =  150 °C

6. Storage temperature : Tstg = -55 to +150 °C


Applications :

High Speed Power Switching


Datasheet PDF Download :
K2959 pdf

Others datasheet of same file : 2SK2959
